  • Specifications
  • Optional Parts
  • Color
Motor:  brushless,rear driving, 48V500W/48V1000W, 8fun
Battery:  Samsung Lithium battery,36V/48V,10.4AH, 13AH
Frame:  Alloy 6061
Front fork:  Suspension fork or Steel with painting
Display:  LED
Light:  LED Front & Rear Light
Controller:  48V 18A intelligent brushless,Kunteng Brand
Wheel:  20inch*4.0, Kenda Brand
Saddle post:  Alloy & suspension, Promax Brand
Derailleur:  7-Speed, Shimano Tourney
Mudguard:  Steel with Painting
Brake:  Front & Rear Disc brake,Tektro Brand
Max Speed 25km/h(EU),30km/h(USA)
Range 35KM by Throttle,70km more by PAS
Max load 100KGS
Net Weight 21.5kg including battery
Gross Weight 26.5kg including package
Carton Size 870*370*780mm
Loading Qty 92pcs/20ft container,208pcs/40GP

Motor : 250W 350W 500W 750W bafang motor

Battery : Samsung 36V 10.4ah/36V 15.6ah/36V 21ah

Samsung 48V 10.4ah/48V 15.6ah/48V 21ah

LCD c800s col orful display(with usb function)

3A special charger
mudguards/rear rack
suspension fork
hydraulic disc brake

Color selection


  •
  •
